RCA RDR9000 User Manual

Service Manual 8. VHF (136-174 MHz) Information
322
No.
Ref. No.
Print No.
Part No.
Description
935
U3009
/
ESV024000000
Audio amplifier IC
936
J4000
/
EMC001000000
RF connector
937
J4001
/
EMC001000000
RF connector
938
J5002
/
EJHS02020000
FPC connector
939
J5001
/
EJBS02000002
Board-to-board connector
940
J5003
/
EJMS00800000
MicroSD card connector
941
S1000
/
MB0005000020
Heat sink
942
W8000
/
EMH001000000
TNC antenna connector
943
A1
/
MM0059000200
Shielding can A
944
A2
/
MM0059000200
Shielding can A
945
A3
/
MM0059000200
Shielding can A
946
A4
/
MM0059000200
Shielding can A
947
B1
/
MM0060000200
Shielding can B
948
B2
/
MM0060000200
Shielding can B
949
B3
/
MM0060000200
Shielding can B
950
C1
/
MM0061000200
Shielding can C
951
D1
/
MM0062000200
Shielding can D
952
E1
/
MM0063000200
Shielding can E
953
E2
/
MM0063000200
Shielding can E
954
/
/
EPPH0020800F
PCB
Table 8-2 Parts List of RDR9000 RX Board

RCA RDR9000 Specifications

General

Brand	RCA
Model	RDR9000
Category	Repeater
Language	English
