RCA RDR9000

Service Manual 8. VHF (136-174 MHz) Information
321
No.
Ref. No.
Print No.
Part No.
Description
896
Q8006
T9H
EFAS02010000
PA MOSFET
897
Q8005
T10H
EFAS02010001
PA MOSFET
898
U1003
T6H
ESH016000004
Power management IC
899
U1002
T5H
ESH016000003
Power management IC
900
U1009
T1J
ESH016000000
Power management IC
901
U1006
T6G
ESH016000002
Power management IC
902
U1010
T4F
ESH016000002
Power management IC
903
U1011
T2D
ESH016000002
Power management IC
904
U1012
T12H
ESH016000002
Power management IC
905
U1013
T12H
ESH016000002
Power management IC
906
U2008
B2H
ESH016000002
Power management IC
907
Q5015
B5B
EFPS03020000
P-MOSFET
908
U8003
B8B
ESE028000000
Current sense amplifier
909
U7000
T10K
ESD017000000
PLL IC
910
D6002
B12H
ESZ017000000
Mixer IC
911
U2006
T4J
ESR002000000
Logic IC
912
U5000
B3D
ESR002000001
Logic IC
913
U5001
B3H
ESR002000001
Logic IC
914
U5002
B5I
ESR002000001
Logic IC
915
U3003
B5H
ESN002000001
Baseband processor IC
916
U4000
B7I
ESF002000000
D/A converter IC
917
U2003
B2J
ESQ002000001
Reset IC
918
U1000
T6E
ESH002000000
Power management IC
919
U1001
T6G
ESH002000001
Power management IC
920
U3010
T3G
ESP002000000
Analog switch IC
921
U3000
T2G
ESP002000001
Switch IC
922
U3008
T2H
ESP002000001
Switch IC
923
D1008
T4B
EDWS03070001
Zener diode
924
D1004
T5C
EDWS03070000
Zener diode
925
D2001
B2H
EDWS03070000
Zener diode
926
Q6000
B13F
ETCS03080001
Compound transistor
927
U501
T8J
ESY013000000
Buffer amplifier IC
928
U2002
B2I
ESH018000000
Power management IC
929
U4008
T2K
EGGS02447000
SAW filter
930
U4009
T2K
ESB008000000
Bluetooth module
931
X4001
T3K
EYBS02605002
Crystal resonator
932
J1000
/
EJZS00600000
Power socket
933
C1000
/
ECE00477M002
470 μF
934
J5000
/
EJZS02600000
D_SUB connector
