RCA RDR9000 User Manual

Service Manual 8. VHF (136-174 MHz) Information
320
No.
Ref. No.
Print No.
Part No.
Description
857
D5007
T3B
EDES13010000
ESD protection diode
858
D5011
B3B
EDES13010000
ESD protection diode
859
D5012
T4A
EDES13010000
ESD protection diode
860
D5016
T5J
EDES13010000
ESD protection diode
861
D5017
B6K
EDES13010000
ESD protection diode
862
D5018
B7K
EDES13010000
ESD protection diode
863
D1002
T5F
EDES13010001
ESD protection diode
864
D2002
T3K
EDES13010001
ESD protection diode
865
D5008
T3B
EDES13010001
ESD protection diode
866
D5014
B7K
EDES13010001
ESD protection diode
867
D5020
T6J
EDES13010001
ESD protection diode
868
U2005
T5I
SMESM003000001
Memory
869
U8011
T13G
ESE010000001
Operational amplifier
870
U1004
T12G
ESH010000002
Power management IC
871
U1005
T12G
ESH010000002
Power management IC
872
U1008
T4F
ESH010000000
Power management IC
873
U3001
B5G
ESE002000001
Operational amplifier
874
U3004
B4G
ESE002000001
Operational amplifier
875
U1007
T5C
ESE010000000
Operational amplifier
876
U3002
T2G
ESE010000000
Operational amplifier
877
U2007
T5K
ESP014000000
Switch IC
878
U3005
B4I
ESP014000001
Three-way analog switch IC
879
U2001
T4K
ESP025000000
Two-way USB analog switch IC
880
U2000
T3I
ESN002000005
Baseband processor IC
881
Q6003
B15H
ETNS04010000
NPN transistor
882
Q6004
B15H
ETNS04010000
NPN transistor
883
Q6013
T12J
ETNS04010000
NPN transistor
884
Q6014
T12K
ETNS04010000
NPN transistor
885
Q7006
T8J
ETNS04010000
NPN transistor
886
D5019
B4K
EDES06010002
ESD protection diode
887
D2010
B5K
EDES06010003
ESD protection diode
888
D5001
T1B
ESJ025000000
USB protection IC
889
D5013
T6K
ESJ025000000
USB protection IC
890
Q1004
T7C
ETNS04040000
NPN transistor
891
D1005
T4C
EDXS03030000
Schottky barrier diode
892
D2000
B2I
EDXS03030000
Schottky barrier diode
893
D2003
B2I
EDXS03030000
Schottky barrier diode
894
D2004
B2I
EDXS03030000
Schottky barrier diode
895
D5015
B6B
EDXS03030000
Schottky barrier diode
