RCA RDR9000 User Manual

Service Manual 7.UHF3 (350-400 MHz) Information
225
No.
Ref. No.
Print No.
Part No.
Description
961
J4000
/
EMC001000000
RF connector
962
J4001
/
EMC001000000
RF connector
963
J5002
/
EJHS02020000
FPC connector
964
J5001
/
EJBS02000002
Board-to-board connector
965
J5003
/
EJMS00800000
MicroSD card connector
966
S1000
/
MB0005000020
Heat sink
967
W8000
/
EMH001000000
TNC antenna connector
968
A1
/
MM0059000200
Shielding can A
969
A2
/
MM0059000200
Shielding can A
970
A3
/
MM0059000200
Shielding can A
971
A4
/
MM0059000200
Shielding can A
972
B1
/
MM0060000200
Shielding can B
973
B2
/
MM0060000200
Shielding can B
974
B3
/
MM0060000200
Shielding can B
975
C1
/
MM0061000200
Shielding can C
976
D1
/
MM0062000200
Shielding can D
977
E1
/
MM0063000200
Shielding can E
978
E2
/
MM0063000200
Shielding can E
979
/
/
EPPH0020800F
PCB
Table 7-2 Parts List of RDR9000 RX Board
