Page #31 background imageLoading...
Page #31 background image
Service Manual 5. Interface Description
21
5. Interface Description
5.1 Internal Interface
TX&RX Board 8-Pin Connector (J2001)
Pin No.
Name
Function
1
OMAP_SYNC
OMAP sync
2
MCBSP0_OPT_DR
McBSP0 RX data
3
ACC3
McBSP0 RX bit clock
4
ACC4
McBSP0 RX frame sync
5
MCBSP0_OPT_FSX
McBSP0 TX frame sync
6
MCBSP0_OPT_Bclk
McBSP0 TX bit clock
7
MCBSP0_OPT_DX
McBSP0 TX data
8
WD_RST
Reset signal
Table 5-1 TX&RX Board 8-Pin Connector (J2001)
