RCA RDR9000 User Manual

Service Manual 6. UHF1 (400-470 MHz) Information
68
6.7 Parts List
RDR9000 TX
Board
No.
Ref. No.
Print No.
Part No.
Description
1
R4015
B7J
ERC02000J000
0 Ω
2
R5067
T3D
ERC02000J000
0 Ω
3
R5100
T2B
ERC02000J000
0 Ω
4
R5107
T2A
ERC02000J000
0 Ω
5
R5108
T3B
ERC02000J000
0 Ω
6
R5125
T5K
ERC02000J000
0 Ω
7
R5130
T5J
ERC02000J000
0 Ω
8
R5134
T6K
ERC02000J000
0 Ω
9
R5135
T6K
ERC02000J000
0 Ω
10
R6007
B12J
ERC02000J000
0 Ω
11
R6010
B12J
ERC02000J000
0 Ω
12
C6021
B12J
ERC02000J000
0 Ω
13
R6071
T12J
ERC02000J000
0 Ω
14
C6090
B15I
ERC02000J000
0 Ω
15
R7029
T8J
ERC02000J000
0 Ω
16
R7046
T10K
ERC02000J000
0 Ω
17
R8020
T14G
ERC02000J000
0 Ω
18
R8074
T15D
ERC02000J000
0 Ω
19
R8085
T14B
ERC02000J000
0 Ω
20
C8089
T8H
ERC02000J000
0 Ω
21
C8106
T9H
ERC02000J000
0 Ω
22
R8119
T15K
ERC02000J000
0 Ω
23
R8126
B7B
ERC02000J000
0 Ω
24
R1022
T6D
ERC03000J000
0 Ω
25
R1026
B7C
ERC03000J000
0 Ω
26
R5147
T4B
ERC03000J000
0 Ω
27
R5148
T4A
ERC03000J000
0 Ω
28
L6015
B14H
ERC03000J000
0 Ω
29
L7019
T8J
ERC03000J000
0 Ω
30
L7040
B9J
ERC03000J000
0 Ω
31
R3117
B2E
ERC05000J000
0 Ω
32
L8017
T9G
ERC05000J000
0 Ω
33
R8121
B8C
ERC0615CF000
0.015 Ω
34
R8122
B8B
ERC0615CF000
0.015 Ω
35
R8123
B8B
ERC0615CF000
0.015 Ω
