RCA RDR9000 User Manual

Service Manual 8. VHF (136-174 MHz) Information
319
No.
Ref. No.
Print No.
Part No.
Description
818
Q6016
T14H
ETCS03020000
Compound transistor
819
Q7000
B8K
ETCS03020000
Compound transistor
820
Q7002
B8K
ETCS03020000
Compound transistor
821
Q7004
B8K
ETCS03020000
Compound transistor
822
Q7008
T11K
ETCS03020000
Compound transistor
823
Q7009
T9K
ETCS03020000
Compound transistor
824
Q5004
T3D
ETCS03020001
Compound transistor
825
Q5020
T13C
ETCS03020001
Compound transistor
826
Q5000
B2D
ETCS03050000
Compound transistor
827
Q5001
B4F
ETCS03050000
Compound transistor
828
Q5002
B6D
ETCS03050000
Compound transistor
829
Q5003
B4D
ETCS03050000
Compound transistor
830
Q5005
B4D
ETCS03050000
Compound transistor
831
Q5006
B4J
ETCS03050000
Compound transistor
832
Q5007
B3D
ETCS03050000
Compound transistor
833
Q5008
B2J
ETCS03050000
Compound transistor
834
Q5009
B6D
ETCS03050000
Compound transistor
835
Q5010
B3D
ETCS03050000
Compound transistor
836
Q5019
B5D
ETCS03050000
Compound transistor
837
D5010
T4B
EDES14010000
ESD protection diode
838
D5024
T4B
EDES14010000
ESD protection diode
839
D5025
T2B
EDES14010000
ESD protection diode
840
D5026
T2B
EDES14010000
ESD protection diode
841
U2004
T2I
ESM032000000
Memory
842
D8004
T12A
EDSS11010000
Switching diode
843
D8005
T13B
EDSS11010000
Switching diode
844
U4006
T1C
ESG020000001
GPS module
845
X2000
T3K
EYAS32771001
Crystal
846
BT2000
B1I
EBE000001000
Button cell
847
Q2001
B2H
ETNS07010000
NPN transistor
848
Q1011
T5C
ETPS07010000
PNP transistor
849
Q1013
T4C
ETPS07010000
PNP transistor
850
D3000
B3F
EDES13010000
ESD protection diode
851
D3001
B4F
EDES13010000
ESD protection diode
852
D5002
T4A
EDES13010000
ESD protection diode
853
D5003
T2A
EDES13010000
ESD protection diode
854
D5004
T3A
EDES13010000
ESD protection diode
855
D5005
T3B
EDES13010000
ESD protection diode
856
D5006
T5B
EDES13010000
ESD protection diode
