Service Manual 8. VHF (136-174 MHz) Information
318
No.
Ref. No.
Print No.
Part No.
Description
779
L8012
B10C
ELF41600Y000
Bead
780
U3006
T3H
ESJ014000000
Noise reduction IC
781
D8008
B8H
EDWS05040000
Zener diode
782
L1001
T5E
ELC00153N000
15 μH
783
L1004
T6H
ELC00622N000
6.2 μH
784
L1000
T6E
ELC00103N000
10 μH
785
U5004
B4K
EGKS00000000
EMI filter
786
U5005
B4K
EGKS00000000
EMI filter
787
U5006
B4K
EGKS00000000
EMI filter
788
U5007
B3K
EGKS00000000
EMI filter
789
Q1003
B6C
ETPS07030000
PNP transistor
790
D1009
T4C
EDSS03010001
Switching diode
791
D6011
T11J
EDSS03010001
Switching diode
792
D7003
B8K
EDSS03010001
Switching diode
793
D8003
T14G
EDSS03010001
Switching diode
794
X7000
T10K
EYDS01925000
TCXO
795
X4001
T3K
EYBS02605002
Crystal oscillator
796
Q1002
T12F
ETBS03040000
Transistor
797
Q1005
T5D
ETBS03040000
Transistor
798
Q1007
T5D
ETBS03040000
Transistor
799
Q1012
T4C
ETBS03040000
Transistor
800
Q1014
T5C
ETBS03040000
Transistor
801
Q2003
T4K
ETBS03040000
Transistor
802
Q5013
B2B
ETBS03040000
Transistor
803
Q5014
T5C
ETBS03040000
Transistor
804
Q8003
B8G
ETBS03040000
Transistor
805
Q8008
T13H
ETBS03040000
Transistor
806
D1007
T4C
EDWS03050000
Zener diode
807
D7010
T8K
EDWS03050004
Zener diode
808
D1006
T5C
EDWS03050003
Zener diode
809
Q1000
T6I
ETCS03020000
Compound transistor
810
Q1009
T4B
ETCS03020000
Compound transistor
811
Q3000
B5F
ETCS03020000
Compound transistor
812
Q3001
B4G
ETCS03020000
Compound transistor
813
Q3002
B4G
ETCS03020000
Compound transistor
814
Q3004
T2G
ETCS03020000
Compound transistor
815
Q6007
B11K
ETCS03020000
Compound transistor
816
Q6009
B11K
ETCS03020000
Compound transistor
817
Q6011
T11I
ETCS03020000
Compound transistor
