RCA RDR9000 User Manual

Service Manual 6. UHF1 (400-470 MHz) Information
97
RDR9000 RX Board
No.
Ref. No.
Print No.
Part No.
Description
1
L8018
T10A
ERC06000F000
0 Ω
2
R2010
B2I
ERC02000J000
0 Ω
3
R2024
T2I
ERC02000J000
0 Ω
4
R2040
T5J
ERC02000J000
0 Ω
5
R2082
T4K
ERC02000J000
0 Ω
6
R2083
T4K
ERC02000J000
0 Ω
7
R2099
T3H
ERC02000J000
0 Ω
8
R2101
T4K
ERC02000J000
0 Ω
9
R2102
T4K
ERC02000J000
0 Ω
10
C2140
T2J
ERC02000J000
0 Ω
11
R3046
B4I
ERC02000J000
0 Ω
12
R3047
B4H
ERC02000J000
0 Ω
13
R3048
B4I
ERC02000J000
0 Ω
14
R3088
T3H
ERC02000J000
0 Ω
15
C3096
T3H
ERC02000J000
0 Ω
16
R3116
B3E
ERC02000J000
0 Ω
17
R4001
B6J
ERC02000J000
0 Ω
18
R4007
B6J
ERC02000J000
0 Ω
19
R4008
B6J
ERC02000J000
0 Ω
20
R4010
B7J
ERC02000J000
0 Ω
21
R4011
B7J
ERC02000J000
0 Ω
22
R5094
B5I
ERC02330J000
33 Ω
23
R5101
T3B
ERC02330J000
33 Ω
24
R5102
T3B
ERC02330J000
33 Ω
25
R5104
T4B
ERC02330J000
33 Ω
26
R5105
T4B
ERC02330J000
33 Ω
27
R5106
T4B
ERC02330J000
33 Ω
28
R5111
T3B
ERC02330J000
33 Ω
29
R5112
T4B
ERC02330J000
33 Ω
30
R5113
T5A
ERC02330J000
33 Ω
31
R5115
T2A
ERC02330J000
33 Ω
32
R5116
T2A
ERC02330J000
33 Ω
33
R5117
T3A
ERC02330J000
33 Ω
34
R5118
T3A
ERC02330J000
33 Ω
35
R5119
T4A
ERC02330J000
33 Ω
36
R5120
T4A
ERC02330J000
33 Ω
37
R5132
T5K
ERC02330J000
33 Ω
