RCA RDR9000

Service Manual 7.UHF3 (350-400 MHz) Information
192
No.
Ref. No.
Print No.
Part No.
Description
849
C6062
B12F
ECC1568AB000
6.8 pF
850
C6064
B14H
ECC1568AB000
6.8 pF
851
C6076
B12G
ECC1568AB000
6.8 pF
852
C8116
T9H
ECC1568AB000
6.8 pF
853
C8061
T9C
ECC2268AC000
6.8 pF
854
C8078
T10C
ECC2268AC000
6.8 pF
855
L6033
T14I
ELW18682K000
6.8 μH
856
R8014
T13G
ERC02683F000
68 kΩ
857
R8130
B10F
ERC02683F000
68 kΩ
858
R1002
T7F
ERC02683F000
68 kΩ
859
R4012
B6I
ERC02683F000
68 kΩ
860
C3033
B5G
ECC15680J000
68 pF
861
C4064
T2B
ECC15680J000
68 pF
862
C6050
B14G
ECC1560AB000
6 pF
863
C6057
B12G
ECC1560AB000
6 pF
864
C6037
B14F
ECC1575AB000
7.5 pF
865
C6040
B14F
ECC1575AB000
7.5 pF
866
C7064
T8K
ECC1575AB000
7.5 pF
867
C7092
B9K
ECC1575AB000
7.5 pF
868
C7093
B9K
ECC1575AB000
7.5 pF
869
C6203
B10J
ECC1575AB000
7.5 pF
870
U6001
B14H
EGCS73354000
73.35 MHz
871
C6144
B14K
ECC1870AB000
7 pF
872
L7004
B9J
ELH0080AZ000
8 nH
873
R2023
T7I
ERC02822J000
8.2 kΩ
874
R5002
B2C
ERC02822J000
8.2 kΩ
875
R5019
B5D
ERC02822J000
8.2 kΩ
876
R5043
B4D
ERC02822J000
8.2 kΩ
877
R5047
B4F
ERC02822J000
8.2 kΩ
878
R5049
B6E
ERC02822J000
8.2 kΩ
879
R5050
B6E
ERC02822J000
8.2 kΩ
880
R5052
B4J
ERC02822J000
8.2 kΩ
881
D6015
B10I
EDVS05020000
Varactor diode
882
D6017
B10I
EDVS05020000
Varactor diode
883
D7002
B9I
EDVS05020000
Varactor diode
884
D7005
B9I
EDVS05020000
Varactor diode
885
Q6001
B12J
ETNS04030000
NPN transistor
