RCA RDR9000 User Manual

Service Manual 7.UHF3 (350-400 MHz) Information
199
R9000 RX Board
No.
Ref. No.
Print No.
Part No.
Description
1
R4011
B7J
ERC02000J000
0 Ω
2
R5094
B5I
ERC02330J000
33 Ω
3
R5101
T3B
ERC02330J000
33 Ω
4
R5102
T3B
ERC02330J000
33 Ω
5
R5104
T4B
ERC02330J000
33 Ω
6
R5105
T4B
ERC02330J000
33 Ω
7
R5106
T4B
ERC02330J000
33 Ω
8
R5111
T3B
ERC02330J000
33 Ω
9
R5112
T4B
ERC02330J000
33 Ω
10
R5113
T5A
ERC02330J000
33 Ω
11
R5115
T2A
ERC02330J000
33 Ω
12
R5116
T2A
ERC02330J000
33 Ω
13
R5117
T3A
ERC02330J000
33 Ω
14
R5118
T3A
ERC02330J000
33 Ω
15
R5119
T4A
ERC02330J000
33 Ω
16
R5120
T4A
ERC02330J000
33 Ω
17
R5132
T5K
ERC02330J000
33 Ω
18
R5133
T6J
ERC02330J000
33 Ω
19
R5136
B6K
ERC02330J000
33 Ω
20
R5137
T5J
ERC02330J000
33 Ω
21
R5138
B5K
ERC02330J000
33 Ω
22
R5139
B5K
ERC02330J000
33 Ω
23
R5140
B5K
ERC02330J000
33 Ω
24
R5141
B4K
ERC02330J000
33 Ω
25
R5142
B6K
ERC02330J000
33 Ω
26
R5144
B2B
ERC02330J000
33 Ω
27
R5145
B5K
ERC02330J000
33 Ω
28
R5149
T3A
ERC02330J000
33 Ω
29
R5151
B5D
ERC02330J000
33 Ω
30
R8006
T14G
ERC02390J000
39 Ω
31
R8007
T15F
ERC02390J000
39 Ω
32
C6214
B11J
ERC02510F000
51Ω
33
R2025
T2I
ERC02510F000
51 Ω
34
R6027
B15H
ERC02510F000
51 Ω
35
R6037
B15J
ERC02510F000
51 Ω
