RCA RDR9000

Service Manual 7.UHF3 (350-400 MHz) Information
215
No.
Ref. No.
Print No.
Part No.
Description
591
Q6006
T15I
ETNS06010000
NPN transistor
592
Q5018
B5B
ETNS03010000
NPN transistor
593
Q6005
T15H
ETNS03010000
NPN transistor
594
Q6008
B11K
ETNS03010000
NPN transistor
595
Q7001
T9J
ETNS03010000
NPN transistor
596
Q7007
T8J
ETNS03010000
NPN transistor
597
Q8000
T13G
ETNS03010000
NPN transistor
598
Q3020
B2E
ETNS03010000
NPN transistor
599
Q6012
B10J
ETNS06010001
NPN transistor
600
Q7003
B9J
ETNS06010001
NPN transistor
601
Q1010
T4B
EFNS06010000
N-MOSFET
602
Q3003
B3G
EFNS06010000
N-MOSFET
603
Q3005
B3G
EFNS06010000
N-MOSFET
604
Q5016
B5B
EFNS06010000
N-MOSFET
605
Q5017
B5B
EFNS06010000
N-MOSFET
606
Q8010
B10F
EFNS06010000
N-MOSFET
607
Q8011
T8H
EFNS06010000
N-MOSFET
608
D1000
T6B
EDES09040000
TVS diode
609
R5055
B5A
ERC02332J000
3.3 kΩ
610
R6059
B10J
ERC02332J000
3.3 kΩ
611
R8088
B9F
ERC02332J000
3.3 kΩ
612
R8145
B10F
ERC02332J000
3.3 kΩ
613
C7018
B9J
ECC1833AB000
3.3 pF
614
C7026
B9J
ECC1833AB000
3.3 pF
615
L6039
B14K
ELW21332K000
3.3 μH
616
C6029
B13F
ECC1536AB000
3.6 pF
617
C6197
B10J
ECC1836AB000
3.6 pF
618
C7021
B10J
ECC1836AB000
3.6 pF
619
R8030
B11F
ERC02392J000
3.9 kΩ
620
R3037
B4G
ERC02303J000
30 kΩ
621
R3041
B3G
ERC02303J000
30 kΩ
622
R3098
T3G
ERC02303J000
30 kΩ
623
R3099
T3F
ERC02303J000
30 kΩ
624
R3100
T3G
ERC02303J000
30 kΩ
625
R3101
T3F
ERC02303J000
30 kΩ
626
R6030
B15H
ERC02303J000
30 kΩ
627
R6034
B15H
ERC02303J000
30 kΩ
