Service Manual 8. VHF (136-174 MHz) Information
292
No.
Ref. No.
Print No.
Part No.
Description
815
R8130
B10F
ERC02683F000
68 kΩ
816
R1002
T7F
ERC02683F000
68 kΩ
817
R4012
B6I
ERC02683F000
68 kΩ
818
C3033
B5G
ECC15680J000
68 pF
819
C4064
T2B
ECC15680J000
68 pF
820
C6050
B14G
ECC1560AB000
6 pF
821
C6057
B12G
ECC1560AB000
6 pF
822
C6037
B14F
ECC1575AB000
7.5 pF
823
C6040
B14F
ECC1575AB000
7.5 pF
824
C7064
T8K
ECC1575AB000
7.5 pF
825
C7092
B9K
ECC1575AB000
7.5 pF
826
C7093
B9K
ECC1575AB000
7.5 pF
827
C6203
B10J
ECC1575AB000
7.5 pF
828
U6001
B14H
EGCS73354000
73.35 MHz
829
C6144
B14K
ECC1870AB000
7 pF
830
L7004
B9J
ELH0080AZ000
8 nH
831
R2023
T7I
ERC02822J000
8.2 kΩ
832
R5002
B2C
ERC02822J000
8.2 kΩ
833
R5019
B5D
ERC02822J000
8.2 kΩ
834
R5043
B4D
ERC02822J000
8.2 kΩ
835
R5047
B4F
ERC02822J000
8.2 kΩ
836
R5049
B6E
ERC02822J000
8.2 kΩ
837
R5050
B6E
ERC02822J000
8.2 kΩ
838
R5052
B4J
ERC02822J000
8.2 kΩ
839
D6015
B10I
EDVS05020000
Varactor diode
840
D6017
B10I
EDVS05020000
Varactor diode
841
D7002
B9I
EDVS05020000
Varactor diode
842
D7005
B9I
EDVS05020000
Varactor diode
843
Q6001
B12J
ETNS04030000
NPN transistor
844
Q6002
B13G
ETNS04030000
NPN transistor
845
L3001
B6H
ELF15601Y000
Bead
846
L3003
B5H
ELF15601Y000
Bead
847
L3004
B6I
ELF15601Y000
Bead
848
L3006
B5I
ELF15601Y000
Bead
849
L3008
B4H
ELF15601Y000
Bead
850
L3011
T4G
ELF15601Y000
Bead
851
L3012
T3G
ELF15601Y000
Bead
852
L3013
T3G
ELF15601Y000
Bead
853
L3014
T3G
ELF15601Y000
Bead
