Service Manual 8. VHF (136-174 MHz) Information
295
No.
Ref. No.
Print No.
Part No.
Description
932
L1010
T6C
ELF41600Y000
Bead
933
L3016
T1E
ELF41600Y000
Bead
934
L3018
T2F
ELF41600Y000
Bead
935
L3019
T2H
ELF41600Y000
Bead
936
L3020
T2G
ELF41600Y000
Bead
937
L3021
B3E
ELF41600Y000
Bead
938
L8007
B7C
ELF41600Y000
Bead
939
L8008
B7B
ELF41600Y000
Bead
940
L8011
B10C
ELF41600Y000
Bead
941
L8012
B10C
ELF41600Y000
Bead
942
U3006
T3H
ESJ014000000
Noise reduction IC
943
D8008
B8H
EDWS05040000
Zener diode
944
L1001
T5E
ELC00153N000
15 μH
945
L1004
T6H
ELC00622N000
6.2 μH
946
L1000
T6E
ELC00103N000
10 μH
947
U5004
B4K
EGKS00000000
EMI filter
948
U5005
B4K
EGKS00000000
EMI filter
949
D5011
B3B
EDES13010000
ESD protection diode
950
D5012
T4A
EDES13010000
ESD protection diode
951
D5016
T5J
EDES13010000
ESD protection diode
952
D5017
B6K
EDES13010000
ESD protection diode
953
D5018
B7K
EDES13010000
ESD protection diode
954
D1002
T5F
EDES13010001
ESD protection diode
955
D2002
T3K
EDES13010001
ESD protection diode
956
D5008
T3B
EDES13010001
ESD protection diode
957
D5014
B7K
EDES13010001
ESD protection diode
958
D5020
T6J
EDES13010001
ESD protection diode
959
U2005
T5I
SMESM003000001
Memory
960
U8011
T13G
ESE010000001
Operational amplifier
961
U1004
T12G
ESH010000002
Power management IC
962
U1005
T12G
ESH010000002
Power management IC
963
U1008
T4F
ESH010000000
Power management IC
964
U3001
B5G
ESE002000001
Operational amplifier
965
U3004
B4G
ESE002000001
Operational amplifier
966
U1007
T5C
ESE010000000
Operational amplifier
967
U3002
T2G
ESE010000000
Operational amplifier
968
U2007
T5K
ESP014000000
Switch IC
969
U3005
B4I
ESP014000001
Three-way analog switch IC
970
U2001
T4K
ESP025000000
Two-way USB analog switch IC
