Service Manual 10. Exploded View
334
No.
Part No.
Description
Qty.
13
EWZ000160000
DB26-to-26 pin IDC connector ribbon
cable
1
14
MD0030028000
Hex stud (M3.0 L=28mm)
4
15
MC2030060100
Countersunk screw (M3 x 6)
8
16
EWC000200003
TNC PLUG TO N JACK
1
17
MD0030000300
Hex nut M3.0
8
18
MC2030035300
Countersunk screw (M3 x 35)
8
19
EZAA2B038000
Fan
2
20
EWC000200002
SMA PLUG TO SMA JACK
1
21
EWZ000410000
12-pin IDC connector ribbon cable
1
22
EWZ000260000
DB26-to-10 pin IDC connector ribbon
cable
1
23
MB0015000000
Y-type connector (3.5-5)
8
24
EWA220510000
2-pin power adapter cable
2
25
/
PCB for rear board and floating charge
board
1
26
MC2040000000
Ground screw M4
1
27
EJEP00010002
AC power socket
1
28
MB0016000000
Y-type connector (2-4)
3
29
MC2030060110
Machine screw (M3 x 6)
10
30
MM0003000300
Cover for rear board PCB
1
31
MM0000000300
Chassis top cover
1
32
EWC000330001
BNC JACK TO TNC PLUG
1
33
MF0000600000
Ground conductive sponge
6
34
EJD290130001
Switched-mode power supply
1
35
MD0030000310
Stud M3.0
4
36
MM0002000300
Chassis bottom cover
1
37
MC2040150200
Machine screw (M4 x 15)
6
38
/
PCB for RX module
1
39
MC2030150200
Machine screw (M3 x 15)
20
40
MC2025050300
Machine screw (M2.5 x 5)
6
41
ENB011572000
Speaker
1
42
MF0000300000
Speaker felt
1
43
/
PCB for control panel
1
44
EUT128160000
TFT LCD
1
45
EWDAB0080001
20-pin data cable
1
46
MD0030000320
Hex stud M3.0
6
47
MR0132000320
Silicone rubber key
1
