Service Manual 12. Specifications
340
4FSK and Magnitude Error
5%/1%
TDMA Mode Transmit Ramp Up
and Ramp Down Time (under
extreme temperature)
< 1.3 ms
Transmitter Lock Time
1.5 ms
TDMA Off Slot Power
-60 dBm
Audio Distortion
Analog: 3%
Digital: 5%
Audio S/N
Analog (W/N): 48 dB/42 dB
Digital: 55 dB
Audio Response
+1 to -3 dB
Transmit Transient Response
Refer to FCC and CE standards.
FM Modulation
11K0F3E @ 12.5 kHz
16K0F3E @ 25 kHz
4FSK Modulation
7K60FXD @ 12.5 kHz (data only)
7K60FXE @ 12.5 kHz (data and voice)
Modulation Maximum Deviation
2.5 kHz @ 12.5 kHz
5.0 kHz @ 25 kHz
GPS/BDS
TIFF Cold Start
< 2 minutes
TIFF Hot Start
< 10 seconds
Horizontal Accuracy
< 10 meters
Tracking Sensitivity
< -152 dBm
Acquisition Sensitivity
< -140 dBm
Power Dissipation
40 mA
All specifications are tested according to applicable standards and subject to change without
notice.
