Service Manual 6. UHF1 (400-470 MHz) Information
57
U4006
MAX_7Q
GND2
1
TXD
2
RXD
3
TIMEPLUSE
4
EXTINT0
5
V_BCKP
6
VCC_IO
7
VCC
8
VRESET
9
GND0
10
RF_IN
11
GND1
12
ANTON
13
VCC_RF
14
RESERVED
15
SDA
16
SCL
17
RESERVED1
18
C4060
NC
C4059
47pF
C4062
2.2uF
C4061
47pF
R4031
1K
3V3GPS
3V3A
L4004
100
12
C4104
470pF
C4068
470pF
13 GPS
R4038 5.6
R4032 33
R4035 33
C4106
2.2uF
C4063
470pF
D4000
1SS390
12
R4033 33
J4000
ANTENNA
1
2 3
GPS_UART_TXD
GPS_UART_RXD
C4069
470pF
TP4007
GPS_int
1
VRTC_3V
R4030
nc
C4067
2.5pF
TIMEPLUSE
C4058
4.7uF
