RCA RLDED5078A-F User Manual

Side Panel Diagram
7
(Left Side)
(Back Side)
Connect to ANT or cable source
PC AUDIO IN
PC audio input
VGA IN
VGA signal from computer output
YPbPr
Connect to the composite terminal of your DVD/VCR
ANT 75 Ω
EARPHONE
For Upgrade Use
AV INPUT
Earphone output
COAXIAL
Digital Audio Output
Service Port
HDMI IN
Connect to HDMI of DVD or other equipment
Name
Function Description
VIDEO/Y
Pb Pr
AC 10 0- 24 0V ~
50/60 Hz
HDMI1
HDMI2
HDMI3
COAXI AL
service p ort

RCA RLDED5078A-F Specifications

General

Brand	RCA
Model	RLDED5078A-F
Category	LED TV
Language	English
