RCA RTDVD1900 - Top;Side Panel Diagram

Side Panel Diagram
7
(Left Side)
(Back Side)
Connect to ANT or cable source
PC AUDIO IN
PC audio input
VGA IN
VGA signal from computer output
YPbPr
Connect to the composite terminal of your DVD/VCR
ANT 75 Ω
EARPHONE
L/R INPUT
Earphone output
Digital Audio Output
HDMI IN
Connect to HDMI of DVD or other equipment
Name
Function Description
R
For Upgrade Use
Service Port
(The service Port is intended for service use only. Please do not connect any device to the port)
INPUT
VIDEO R
L
Digital
Audio out
service port
EARPHONE
DC IN
INPUT
Y Pb
Pr
PC AUDIO
INPUT
VGA
ANT 75
HDMI
Digital Audio Out
