9
ENGLISH
_
+
SPECIFICATIONS
Connect the amplifier positive output (+, 100 V, a) to the white wire of the
loudspeaker cable.
Connect the amplifier negative output (–, 0, COM, b) to the black wire of the
loudspeaker cable.
Before turning the amplifier on, check the connections again.
DM 41, DM 41-B DM 61
Enclosure: Two-way closed box Two-way closed box
Transducers: 3.5” woofer,
1” tweeter with Mylar cone
6” woofer,
1” tweeter with Mylar cone
Sensitivity (1 W, 1 m): 87 dB 89 dB
Frequency response (-10 dB): 100 Hz ÷ 20 kHz 70 Hz ÷ 20 kHz
Max. sound pressure
(musical power): 102 dB 106 dB
Musical power / RMS: 30 /15 W 50 / 25 W
Low impedance input setting: 8 Ω 8 Ω
100 V line power taps 15 – 7.5 – 5 – 2.5 – 1.25 W 25 – 12.5 – 7.5 – 5 – 2.5 W
Crossover frequency: 2.5 kHz 6 kHz
Filter slope: 6 dB / octave 6 dB / octave
Coverage angle: 170° vertical x 180° horizontal 140° vertical x 120° horizontal
Enclosure material: Autoextinguishing plastic Autoextinguishing plastic
Use: Indoor – outdoor Indoor – outdoor
IP grade: IP 55 IP 55
Dimensions (w, h, d): 130 mm, 197 mm, 115 mm 216 mm, 289 mm, 177 mm
Colour: white (DM 41),
black (DM 41-B)
white
Net weight
(without mounting accessory): 1.8 kg 4 kg
