7
ENGLISH
WARNING
CONNECTION
WARNING: loudspeaker connections should be only made by qualified and
experienced personnel having the technical know-how or sufficient specific
instructions to ensure that connections are made correctly and to prevent any
electrical danger.
To prevent any risk of electric shock, do not connect loudspeakers when the
amplifier is switched on.
Before turning the system on, check all connections and make sure there are
no accidental short circuits.
The entire sound system shall be designed and installed in compliance with
the current local laws and regulations regarding electrical systems.
The internal transformer allows the connection to 100 V constant voltage
lines and the power selection (during the installation) among the values
10 W – 5 W.
As alternative, it is possible to connect the loudspeaker to an amplifier 8 Ω
output.
WARNING
THE SELECTION IS MADE CONSIDERING THE WIRE COLOURS
COLOUR POWER VOLTAGE IMPEDANCE
YELLOW 10 W 100 V 1 kΩ
GREEN 5 W 100 V 2 kΩ
BLUE COMMON WIRE
RED 10 W 8 Ω
