Input channels: EQ section
The 4-band EQ page is identical for all input channels - including TK channels. This page is characterized by the large
Preset box, followed by Standard and Advanced boxes and ON switch.
Great versatility is provided by allowing the selection of three different types of equalizer: Standard (a no-frills,
precise EQ), Vintage (modeled after a UK classic EQ), Smooth (whose modeling was inspired by a modern US EQ). You
have a wide choice that can help in providing the right color to your sound. For each of the three equalizer types, two
options are available: Advanced (showing all the available parameters) and Easy (in which some of the more
advanced controls are hidden to enable a quicker interaction).
shows the operation of the 4-band
equalizer (the overall intervention is
indicated by a white line). The
Advanced option provides variable
frequency shelving filters for low
and high bands and two fully
parametric mids, while the Easy
option provides high and low
shelving with fixed frequency, and
selection of the frequency for mid-
low and mid-high.
The range of intervention goes from
-12.00dB to +12.00dB; double
clicking on the GAIN resets the
value to 0.00dB for each band,
while to completely turn off the
equalizer, you have a global
ON/OFF button right above the
display.
All three models, with the Advanced option, have the following frequency ranges;
Band Freq. Range
