SPECIFICATIONS - PL6X
ACOUSTIC SYSTEM
Transducers
Nominal/maximum power
Frequency range:
Dispersion angle as function of vocal
intelligibility (-6dB):
Directivity factor Q (DI):
Sensitivity :
SPL at program power:
Impedance:
Input Voltage:
Selectable power values:
PHYSICAL CHARACTERISTICS
Material:
Attachment system:
Inputs:
Dimensioni (Ø x H):
Flush mount hole:
Net weight :
Min/max ceiling thickness:
Maximum tailing:
Protection:
6” woofer with coaxial tweeter
12/24 W
70 Hz – 20 kHz
100°
9 (9,5)
92 dB a 1 W 1 m
106 dB 1m at program power
70V-12W : 400 ohm
100V-12W / 70V-6W : 800 ohm
100V-6W / 70V-3W : 1600 ohm
100V-3W / 70V-1,5W : 3300 ohm
70V,100V
70 V: 12-6-3-1,5 W
100 V: 12-6-3-1,5 W
Main body in plastic material,
steel grille
Flush mount
6 pin terminal block
204 x 73 mm
182 mm
1,2 kg
8/30 mm
7 mm
IP44
