RCF PL40 - Specifications - PL8 X; Acoustic System Specifications; Physical Characteristics

17
ENGLISH
8” woofer with coaxial tweeter
20/40W
60 Hz – 20 kHz
80°
11 (10)
93 dB a 1 W 1 m
109 dB 1m at program power
70V-20W : 250 ohm
100V-20W/70V-10W : 500 ohm
100V-10W/70V-5W : 1000 ohm
100V-5W/70V-2,5W : 2000 ohm
100V-2,5 W : 4000 ohm
70V,100V
70 V: 2,5 W- 5 W – 10 W- 20 W
100 V: 2,5 W- 5 W – 10 W – 20 W
Main body in plastic material,
steel grille
Flush mount
6 pin terminal block
247 x 88 mm
224 mm
1,8 kg
8/30 mm
8 mm
IP44
ACOUSTIC SYSTEM
Transducers
Nominal/maximum power
Frequency range:
Dispersion angle as function of vocal
intelligibility (-6dB):
Directivity factor Q (DI):
Sensitivity :
SPL at program power:
Impedance:
Input Voltage:
Selectable power values:
PHYSICAL
CHARACTERISTICS
Material:
Attachment system:
Inputs:
Dimensioni (Ø x H):
Flush mount hole:
Net weight :
Min/max ceiling thickness:
Maximum tailing:
Protection:
SPECIFICATIONS - PL8X
