RCRCM Strega - Page 8

8
Figure 6. Prepare the servo horns and clevises for the wing servos. First drill a hole through the servo horns
(for choice of drill see figure 4) 2,5mm outside the servo horn base (upper panels). The clevises will need to
be milled on the bottom side to allow for full movement respective to the servo horn shaft (middle panel
and lower left panel). Once that is done the clevis allows for full movement when mounted on the servo
horn (lower right).
Once the servo horns and clevises are readily prepared the servo frames need to be adjusted for
perfic fit and test fitted in the servo bays. See, figure 7.
