10
The remote control sensor at the front of the soundbar is sensitive to the remote
control’s commands up to a maximum of 7 metres away and within a maximum
arc of 30 degrees.
Please note that the operating distance may vary depending
on the brightness of the room.
FRONT VIEW
30
30
275.5inches(7m)
POWER SUPPLY
NOTE:The AC input of the adater is 100~240V, 50/60Hz, the output is 24V, 2A.
1. Insert the plug into the other part as shown in step 1.
1
2
3
2. Insert the DC plug to the DC IN jack on the rear of the unit.
3. Insert the AC plug into the AC outlet.
POWER
DC IN
AC Outlet
20V,2.5A.20V,2.5A.
