16. Parts Lists & Diagrams - cont.
NO. DESCRIPTION QUANTITY
1 Cutter block 1
2 Blade holder 3
3 Hex head screw M6 x 12 mm 12
4 Blade 3
5 Spacer 16
6 Bearing cover 2
7 Bearing 6205 2
8 Circle ring 52 mm 2
9 Set screw M6 x 12 mm 6
10 In- feed roller 1
11 Outfeed roller 1
12 Bearing house, front 1
13 Handle wheel, raising 1
14 Raise guide rod 1
15 Spacer 1
16 Spacer 1
17 Thrust bearing 51102 1
18 Hex lock nut M10 2
19 Spring washer 6 mm 2
NO. DESCRIPTION QUANTITY
20 Hex head screw M6 x 60 mm 2
21 Set screw M8 x 12 mm 4
22 Oil seal 1
23 Hex screw M8 x 16 mm 10
24 Hex screw M8 x 35 mm 4
25 Spring washer 8 mm 4
26 Hex nut M6 2
27 Hex screw M6 x 55 mm 1
28 Carriage bolt M6 x 40 mm 1
29 Washer 6 mm 1
30 Pan head screw M4 x 10 mm 2
31 Cross sunk head screw M4 x 8 mm 12
32 Circle ring 18 mm 1
33 Roll pin 5 x 10 mm 1
34 Collar 1
35 Set screw M8 x 8 mm 1
36 Washer 10 mm 1
37 Roll pin 2.5 x 12 mm 1
