Record Power SC3 - Chuck Insert

19
7. Contents of the Packages
1 2* 3*
1 Chuck insert
2 Protective leather disc*
3 M6 x 6 mm blind set screw*
*The blind set screw and protective disc are only supplied with inserts of the following thread sizes:
62125 Thread Adaptor RH M33 x 3.5 ISO
62132 Thread Adaptor 1-1/4"x8 TPI UNS-RH for DVR-XP & 1624-44 Lathes
62133 Thread Adaptor 1” x 8 TPI UNC RH
The chuck inserts are available in the following thread sizes:
62113 Thread Adaptor M20 x 1.5 RH
62125 Thread Adaptor RH M33 x 3.5 ISO
62128 Thread Adaptor 3/4” x 16 TPI UNF RH
62130 Thread Adaptor RH M30 x 3.5 RH
62132 Thread Adaptor 1-1/4” x 8 TPI UNS-RH for DVR-XP & 1624-44 Lathes
62133 Thread Adaptor 1” x 8 TPI UNC RH
62152 Thread Adaptor M18 x 2.5 RH
62157 Thread Adaptor Blank. Can be bored up to 30 mm
Chuck Insert
