43
20. 62337 Pen Jaws
21. 62572 87 mm (3
1
⁄2”) Faceplate Ring
22. 62574 126 mm (5”) Faceplate Ring
This large faceplate ring is ideal for holding large bowl
blanks and due to its strong hold is also suitable for more
out of balance timber. It is held to the chuck using the
standard 50 mm jaw set which comes complete with all
Record Power chuck packages.
Must be used with 62313 50 mm Standard Jaws
(Supplied with SC3 and SC4 chucks).
Diameter: 126 mm (5”)
Mount the faceplate to the centre of the workpiece and
secure in place with 9 number 10 wood screws. Ensure
the recess is facing outwards and attach the faceplate to
the 62313 50 mm Standard Jaws.
126 mm
