19. 62336 Mini Spigot Jaws with 13 mm Bore
To complement the pin jaws, the mini spigot jaws have
also been improved. These jaws perform many of the
same tasks in expansion and the extra screw hole profiles
and added teeth to the outside provide tremendous grip
for when this area will not be visible in the finished work
piece. This set has been given a 13 mm internal diameter,
making it ideal for turning strong spigots on knobs and
handles, again adding to their versatility.
Expansion: 26 - 46 mm (1 - 1
3
⁄4”)
Contraction (spigot): 13 - 33 mm (
1
⁄2 - 1
1
⁄4”)
Contraction (square): 11 - 31 mm (
3
⁄8 - 1
1
⁄4”)
Fig 19.1 shows the jaws holding the spigot of a drawer
/ door handle.
Fig 19.2 shows the jaws expanding into a grinding mill
recess.
Fig 19.1
Fig 19.2
5 mm
26 mm
79.5º 90º
