Record Power SC3 - 62322 75 mm Heavy Bowl and Gripper Jaws; These new jaws are ideal for heavy bowls and vases.; 62323 Long Nose Jaws; These extremely flexible jaws feature internal and external dovetails for bowl work.

39
16. 62322 75 mm Heavy Bowl and Gripper Jaws
These new jaws are ideal for heavy bowls and vases. The
wide front face provides a good register for the base of
the bowl or vase and the deep toothed body provides
strong grip on the spigot. The internal gripper can also
be used on smaller rough green timber. Also featuring an
external dovetail in expansion, they can be used for large
platters. A truly versatile and solid jaw set.
Expansion: 81 - 102 mm (3
1
⁄4 - 4”)
Contraction (spigot): 46 - 65 mm (1
3
⁄4 - 2
1
⁄2”)
Contraction (square): 33 - 54 mm (1
1
⁄4 - 2
1
⁄8”)
5 mm
11 mm
29 mm
79.5º 78º
17. 62323 Long Nose Jaws
These extremely flexible jaws feature internal and
external dovetails for bowl work. The deep internal grip is
versatile but main benefit of these jaws is to project the
work away from the chuck, allowing good tool access to
the base of the timber for cleaning and shaping.
Expansion: 54 - 74 mm (2
1
⁄8 - 2
7
⁄8”)
Contraction (spigot): 38 - 58 mm (1
1
⁄2 - 2
1
⁄4”)
Contraction (square): 27.5 - 48 mm (1
1
⁄8 - 1
7
⁄8”)
3 mm
11 mm
53 mm
79.5º 61º
