42
20. 62337 Pen Jaws
These jaws are fantastically effective for drilling pen
blanks. They eliminate the need for a drill press and offer
much more accurate results and the deep grip to all
four sides ensures incredible holding power. Drilling on
the lathe means the feed speed of the drill bit is under
your complete control, meaning a superior finish can
be achieved on a wide range of materials. These jaws
are also useful for working on small finials and similar
projects as in addition to their strong grip, the work
piece is moved forward from the chuck, allowing greater
access.
Contraction (spigot): 11 - 20 mm (
3
⁄8 -
3
⁄4”)
Contraction (square): 10 - 26 mm (
3
⁄8 - 1”)
21. 62572 87 mm (3
1
⁄2”) Faceplate Ring
This faceplate ring is ideal for holding medium sized bowl
blanks and due to its strong hold is also suitable for more
out of balance timber. It is held to the chuck using the
standard 50 mm jaw set which comes complete with all
Record Power chuck packages.
Must be used with 62313 50 mm Standard Jaws
(Supplied with SC3 and SC4 chucks).
Diameter: 87 mm (3
1
⁄2”)
Mount the faceplate to the centre of the workpiece and
secure in place with 4 number 10 wood screws. Ensure
the recess is facing outwards and attach the faceplate to
the 62313 50 mm Standard Jaws.
SC3 & SC4 Manual 3.7.indd 42SC3 & SC4 Manual 3.7.indd 42 22/04/2022 13:07:0022/04/2022 13:07:00
