Fig 11.9
11. General Jaw Use
Fig 11.10
Turning a Square Spigot
Square spigots can be held in the chuck jaws as shown
in Fig 11.9.
Using the Inner Teeth of the Jaws
Some jaws feature deep internal teeth to give an extra
strong grip to timber. This is ideal when turning large and
heavy work which needs a strong spigot to support it,
see Fig 11.10.
Green timber can also be turned using the inner teeth.
It is recommended that the section to be held is turned
between centres to a cylinder. This will maximise the grip
of the teeth.
