Record Power SC3 - 62313 50 mm Standard Jaws; Important: The jaws feature a small lip to the front of the interior profile.

37
Fig 13.1
Important: The jaws feature a small lip to the
front of the interior profile. This lip is intended
to bite into the wood to give additional security.
Do not turn a spigot to match this profile as the
effectiveness of the jaws will be reduced if the
lip cannot bite, Fig 13.1.
i
Kg
i
Kg
13. 62313 50 mm Standard Jaws
Featuring a specialised dovetail profile in expansion and
the superb grip of the hawk beak design on contraction,
these versatile jaws are a great all-round set, capable of
bowl work to a good size and also spigot turning. They
are supplied as standard with the SC3 and SC4 chucks.
Expansion: 52 - 72 mm (2 - 2
7
⁄8”)
Contraction (spigot): 42 - 61 mm (1
5
⁄8 - 2
3
⁄8”)
Contraction (square): 30 - 51 mm (1
1
⁄8 - 2”)
10.5 mm12.5 mm
79.5º 90º
