24. 62377 Remounting Jaws Mega - Up to 295
mm Bowl (With Angular Buffer Stops)
In response to many requests, we have increased the
capacity of our larger remounting jaws, whilst ensuring
they can still clear the bed of lathes with the popular 12”
swing capacity and are capable of holding 275 mm (10
3/4”) diameter bowls in contraction mode. Remounting
jaws are incredibly popular due to their flexibility. They
work in both contraction and expansion modes and can
be fitted behind other jaw sets to create bespoke set-ups
to make turning more efficient. The soft stoppers are
designed to hold without causing damage, making them
ideal for remounting finished or partly finished objects
for further work.
Expansion: 53 - 316 mm (2 - 12
1
⁄2”)
Contraction (spigot): 55 - 272 mm (2
1
⁄8 - 10
3
⁄4”)
Contraction (square): 51 - 250 mm (2 - 9
7
⁄8”)
Also included with these jaws are a set of angular
stoppers, featuring a tapered profile to give optimum grip
to the workpiece as shown in Fig 24.1. They also feature
two curved sides which give support to 6” and 12”
diameter workpieces as shown in Fig 24.2.
See Fig 24.3 for examples of how different shaped work
can be held.
9 mm
Fig 24.1
Fig 24.2
Important: Extra care must be taken due to the
size of the remounting jaws. Before starting
the lathe always ensure the jaws clear the
lathe bed, tool rest and any other possible
obstructions.
