Record R 62 - Parameter Display; Parameter Overview

Commissioning 5
BAL_SD_R62_EN_2V3_BLA_121-006454377 21 / 30
5.4 Parameter display
Page layout
Secu ri ty Port al XXX
Vers io n : X.XX .X X
Info : OK !
Time : XX: XX :X X
Date : XX. XX .X X
The following information is displayed:
– Current program details
– Software Version
– Information message (current operating mode, main-
tenance required, etc.)
– Date and time of the system
5.5 Parameter overview
PARAMETERS FACTORY
SETTINGS
DESCRIPTION
→ CUSTOMER
→ Customer 0 Parameter to select special customer functions:
0 = Standard
1 = Toronto
→ SENSOR
→ PSensorType 2 Select the type of sensor:
0 = no sensor
1 = contact mat
2 = IEE 3D – Tailgaiting sensor
3 = external approval
