→ OPERATING MODES
→ LOCKED
→ PDetection OFF Protection against confinement in the LOCKED operat-
ing mode:
ON: detection in the portal reopens the last opened door
OFF: doors close and lock (danger of confinement)
→ SLUICE MODE
→ TPubOpenDelay 5 (ds) Delay time to open the door "public side" in sluice mode
→ TSecOpenDelay 5 (ds) Delay time to open the door "secure side" in sluice mode
→ TLedInterval 5 (ds) Traffic lights interval in sluice mode
→ TPubWaitIN 40 (ds) Time waiting for a person to go into the sluice from the
public side before the door closes again
→ TSecWaitIN 40 (ds) Time waiting for a person to go into the sluice form the
secure side before the door closes again
→ TDelayIdle 10 (ds) Delay time to check is door is empty
→ TTimeDecision 10 (sec) Timeout waiting for verification (this could be an external
selection, finger print, contact mat sensor etc.)
→ MAINTENANCE
→ PArea PUB Select from which side maintenance can be done:
PUB = public side
SEC = secure side
→ TLedIntervall 10 (ds) Traffic lights blinking interval during maintenance mode
→ Override OFF Switch on maintenance mode via Service Display (in any
operating mode)
→ CLEANING
→ TDuration 10 (min.) Time allotted for cleaning mode
→ TWarningExit 50 (ds) Warning signal (buzzer or optional voice message), to
exit the door as the cleaning time has expired
→ PANIC
→ TPubOpenDelay 5 (ds) Delay time to open the door "public side" in panic mode
→ TSecOpenDelay 5 (ds) Delay time to open the door "secure side" in panic mode
→ TRAFFIC LIGHTS
→ PTrafficeLEDIdle gn (green) Color of traffic lights when the security portal is empty:
gn = green
red = red
→ LOCK-DOWN
→ PExitWay PUB Select which door will open as exit way when the lock-
down button is pressed. First the opposite door will close
for security reason.
PUB = public side
SEC = secure side
→ DOOR LOCKING
→ Safety locking OFF Locking function that always locks the opposite door
when one door isn't closed.
