Commissioning 5
BAL_SD_R62_EN_2V3_BLA_121-006454377 27 / 30
DIAGNOSTICS FACTORY
SETTINGS
DESCRIPTION
→ StgSecSurV OFF (read only) Command lock secure door
→ StgSecSSK OFF (read only) Command open secure door
→ StgPubSurV OFF (read only) Command lock public door
→ StgPubSSK OFF (read only) Command open public door
→ Light OFF (read only) Lighting
→ Buzzer OFF (read only) Buzzer
→ RedSecOut OFF (read only) Red traffic light secure door outside
→ GreenSecOut OFF (read only) Green traffic light secure door outside
→ RedPubOut OFF (read only) Red traffic light public door outside
→ GreenPubOut OFF (read only) Green traffic light public door outside
→ RedSecIn OFF (read only) Red traffic light secure door inside
→ GreenSecIn OFF (read only) Green traffic light secure door inside
→ RedPubIn OFF (read only) Red traffic light public door inside
→ GreenPubIn OFF (read only) Green traffic light public door inside
→ AUX11_OUT OFF (read only) Programmable output AUX11_OUT
→ AUC21_OUT OFF (read only) Programmable output AUX21_OUT
→ OUTPUTS 48..63
→ Voice1In1 OFF
(read only) Outputs for voice card. Messages are selec-
ted by the binary code of the 4 output signals
→ Voice1In2 OFF
→ Voice1In3 OFF
→ Voice1In4 OFF
→ Voice1Start OFF (read only) Start signal for the selected voice message
→ AUX22_OUT OFF (read only) Programmable output AUX22_OUT
→ AUX23_OUT OFF (read only) Programmable output AUX23_OUT
→ AUX12_OUT OFF (read only) Programmable output AUX12_OUT
→ Flash OFF (read only) Flashing lights outside the door
→ ReverseOUT1 OFF (read only) Not in use
→ ReverseOUT2 OFF (read only) Not in use
→ ReverseOUT3 OFF (read only) Not in use
→ ReverseOUT4 OFF (read only) Not in use
→ ReverseOUT5 OFF (read only) Not in use
→ ReverseOUT6 OFF (read only) Not in use
→ ReverseOUT7 OFF (read only) Not in use
→ OUTPUTS 64..79
