5 Commissioning
26 / 30 BAL_SD_R62_EN_2V3_BLA_121-006454377
DIAGNOSTICS FACTORY
SETTINGS
DESCRIPTION
→ INPUTS 0..15
→ DoorSecClosed OFF (read only) Secure door closed
→ DoorSecOpen OFF (read only) Secure door open
→DoorSecLocked OFF (read only) Secure door locked
→ DoorPubClosed OFF (read only) Public door closed
→ DoorPubOpen OFF (read only) Public door open
→ DoorPubLocked OFF (read only) Public door locked
→DCPowerOK OFF (read only) Monitoring power supply (DC power ok)
→ EmergClosing OFF (read only) Contact emergency closing
→ TotalOpening OFF (read only) Contact total opening
→ PanicButton OFF (read only) Contact panic button
→ AlarmStgSec OFF (read only) Alarm door drive secure side
→ AlarmStgPub OFF (read only) Alarm door drive public side
→ AUX01_IN OFF (read only) Programmable input AUX01_IN
→ AUX02_IN OFF (read only) Programmable input AUX02_IN
→ AUX11_IN OFF (read only) Programmable input AUX11_IN
→ AUX21_IN OFF (read only) Programmable input AUX21_IN
→ INPUTS 16..31
→ BdeS1 OFF (read only) BDE-S contact 1
→ BdeS2 OFF (read only) BDE-S contact 2
→ BdeS3 OFF (read only) BDE-S contact 3
→ AUX12_IN OFF (read only) Programmable input AUX12_IN
→ SwDoorPubOut OFF (read only) Contact public door outside (push button,
code card reader etc.)
→ SwDoorPubIn OFF (read only) Contact public door inside (push button, code
card reader etc.)
→ SwDoorSecOut OFF (read only) Contact secure door outside (push button,
code card reader etc.)
→ SwDoorSecIn OFF (read only) Contact secure door inside (push button,
code card reader etc.)
→ SuperUserSec OFF (read only) Contact for temporary deactivation of the
sensor (contact mat, tailgaiting etc.) to pass through
from the secure side to the public side
→ SuperUserPub OFF (read only) Contact for temporary deactivation of the
sensor (contact mat, tailgaiting etc.) to pass through
from the public side to the secure side
→ SensorC1 OFF (read only) Contact status sensor "room empty"
→ SensorC2 OFF (read only) Contact status sensor "decision YES“
→ SensorC3 OFF (read only) Contact status sensor "decision NO"
→ SwTraps OFF (read only) Service flap is open
→ Voice1Busy OFF (read only) Output of the voice card when busy
→ AUX22_IN OFF (read only) Programmable input AUX22_IN
→ OUTPUTS 32..47
To Next Page
