Record R 62 - Page 25

Commissioning 5
BAL_SD_R62_EN_2V3_BLA_121-006454377 25 / 30
BMS – (Building Management System) FACTORY
SETTINGS
DESCRIPTION
→ PLogicRL1 NORM
Output logic of the relay contact:
NORM: enabled when message is active
INV: enabled when message is inactive
→ PLogicRL2 NORM
→ PLogicRL3 NORM
→ PLogicRL4 NORM
→ PLogicRL5 NORM
→ PLogicRL6 NORM
→ PLogicRL7 NORM
→ PLogicRL8 NORM
SETTINGS FACTORY
SETTINGS
DESCRIPTION
→ DATE AND TIME
→ GetTimeDate OFF Read time from PLC
→ SetTimeDate OFF Write time to PLC
→ Hour 0 .. 23 (Integer) Hour value
→ Minute 0 .. 59 (Integer) Minute value
→ Day 1 .. 31 (Integer) Day value
→ Month 1 ..12 (Integer) Wert Monat
→ Year 2015 .. 2099 (Integer) Year value
→ TCP / IP
→ Get settings OFF Read TCP/IP settings from the PLC
→ Set settings OFF Write TCP/IP settings to the PLC
→IP0 10 (Integer) IP-Adress byte 0
→ IP1 17 (Integer) IP-Adress byte 1
→ IP2 15 (Integer) IP-Adress byte 2
→ IP3 30 (Integer) IP-Adress byte 3
→ Subnet0 255 (Integer) Subnet Mask byte 0
→ Subnet1 255 (Integer) Subnet Mask byte 1
→ Subnet2 255 (Integer) Subnet Mask byte 2
→ Subnet3 0 (Integer) Subnet Mask byte 3
→ Gateway0 0 (Integer) Gateway byte 0
→ Gateway1 0 (Integer) Gateway byte 1
→ Gateway2 0 (Integer) Gateway byte 2
→ Gateway3 0 (Integer) Gateway byte 3
