Record R 62 - Page 24

5 Commissioning
24 / 30 BAL_SD_R62_EN_2V3_BLA_121-006454377
→ VOICE OUTPUT
→ PEnableMsg1 ON enable / disable the voice message 1
→ PEnableMsg2 ON enable / disable the voice message 2
→ PEnableMsg3 ON enable / disable the voice message 3
→ PEnableMsg4 ON enable / disable the voice message 4
→ PEnableMsg5 ON enable / disable the voice message 5
→ PEnableMsg6 ON enable / disable the voice message 6
→ PEnableMsg7 ON enable / disable the voice message 7
→ PEnableMsg8 ON enable / disable the voice message 8
→ PEnableMsg9 ON enable / disable the voice message 9
→ PEnableMsg10 ON enable / disable the voice message 10
→ PEnableMsg11 ON enable / disable the voice message 11
→ PEnableMsg12 ON enable / disable the voice message 12
→ PEnableMsg13 ON enable / disable the voice message 13
→ PEnableMsg14 ON enable / disable the voice message 14
→ PEnableMsg15 ON enable / disable the voice message 15
→ TBewtweenMsg 3 (min.) Delay time to repeat the voice message when the same
function/message is still triggered
→ INPUTS
→ AUX01_IN 0 0 = no function
1 = maintenance mode
2 = cleaning mode from secure side
3 = cleaning mode from public side
4 = Tailgaiting sensor off (permanent deactivation)
→ AUX02_IN 0
→ AUX11_IN 0
→ AUX12_IN 0
→ AUX21_IN 0
→ AUX22_IN 0
→ OUTPUTS
→ AUX11_OUT 0
0 = no function
1 = Person passage from public side
2 = Person passage from secured side
→ AUX12_OUT 0
→ AUX21_OUT 0
→ AUX22_OUT 0
→ AUX23_OUT 0
BMS – (Building Management System) FACTORY
SETTINGS
DESCRIPTION
→ BMS Invert logic
→ BMS1
→ PLogicRL1 NORM
Output logic of the relay contact:
NORM: enabled when message is active
INV: enabled when message is inactive
LOCK: Status message when door is locked
CLOS: Status message when door is closed
→ PLogicRL2 NORM
→ PLogicRL3 NORM
→ PLogicRL4 NORM
→ PLogicRL5 NORM
→ PLogicRL6 NORM
→ PLogicRL7 NORM
→ PLockedClosedRL7 LOCK
→ PLogicRL8 NORM
→ PLockedClosedRL8 LOCK
→ BMS2
