Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 15/ 56
→ RED battery X Standard setting for escape route doors.
▪ This door type can only be selected for redundant control
units with appropriate software.
▪ Standard and emergency channels are checked at least
every 24 hours for correct functioning. Normally, the re-
dundancy test occurs after approx. 22 to 23.5 hours on an
open door with a special door movement. If the door re-
mains open for more than 23.5 hours the test can also take
place in closed position.
▪ Triggering sensors in escape direction (AKI) must also be
redundant. At every door opening triggered by those sen-
sors, time data are controlled on the escape route door.
→ RED door closed Variant for escape route doors, with which the redundancy test
can only be carried out in closed position.
▪ Attention: such a configuration does not necessarily com-
ply with the norm requirements.
CO48 Ventouse Door with mechanical power storage device. A rubber cord is
fixed to an onboard carriage. The carriage is maintained in
closed position by a magnet to relieve the drive. A switch indi-
cates any break of the rubber cord.
▪ Possible with drive height 200 mm.
Parameter Default value
Drive Power failure Emergency operation
Input/Output STG AUX1_IN Broken rubber cord
TOS
For doors with swivelling door leaf. The swivelling movement is
monitored with a switch connected at the Emergency stop
input. Optionally, mechanical locking devices operated by
hand can be mounted on the door leaf.
▪ Manual locking devices are connected to inputs AUX2_IN
and AUX3_IN of function extension module FEM0
(0V/open = manual locking open). The appropriate param-
eter must be configured manually to the signals TOS_DV1
and TOS_DV2.
▪ So that anti-burglary protection is guaranteed, manual
locking devices must be closed in the operating mode
Locked
. Otherwise, error 29 is raised.
▪ If operating mode
Locked
has not been selected the man-
ual locking devices must be open. Otherwise, the door
stops and error 30 is raised.
The SSK function is ensured.
