Record system 20 - Page 16

Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 16/ 56
FlipFlow Folding door application with double swing leaf (DDF).
▪ Increased force and speed when closing.
▪ NSK/SÖK speed is adjustable. Attention: Safety signals
are not monitored. Increasing the speed reduces personal
safety at the expense of e.g. building security.
▪ Increased reaction level for collision surveillance.
▪ A new closed position will only be adopted after 20 colli-
sions.
▪ With a Flip-Flow, the A-
measure (opening width) cannot be
automatically learned. For optimal motion sequence it
therefore has to be configured manually.
▪
Default parameters:
Parameter Default value
Door system → A-measure 900
Driving cycle → Closing speed 18
Driving cycle → Opening speed 40
Driving cycle → Open → Accel-
eration
38
Driving cycle → Open → Decel-
eration
38
Driving cycle → Close → Accel-
eration
33
Driving cycle → Close → De-
celeration
33
Time delay open → Time delay
SSK
0
Drive → Battery Lead
Control panel → Default oper-
ating mode
Automatic
Locking → Lock type Bistable
Locking → Closed VRR Error Enabled
Input/Output → STG →
AUX0_IN
SÖK_NSK
Input/Output → STG →
AUX1_IN
SURV
Input/Output → STG →
SÖK_NSK → Function
NSK locked,
SSK enabled
