Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 26/ 56
→ Locking type Selection of the connected locking device. Due to the large
range of variants, the locking type cannot be identified auto-
matically.
→ Without X No locking device is connected.
→ Motor-powered VRR 20 (motor-powered, bi-stable)
→ Bi-stable VRR 16 (magnetic, bi-stable)
→ MPV 20 Multipoint locking device for system 20 (motor-powered)
→ MPV 16 Multipoint locking device for system 16 (motor-powered)
→ Magnet Magnet locking device (without VAK) unlocked without current
(mono-stable)
→ Fail secure Mono-stable locking device, locked without current
→ Fail safe Mono-stable locking device, unlocked without current
(France: sécurité positive)
→ Double Control of the additional unit for 2 locking devices.
Is used with FBO and PST.
→ Start delay 0 Delay time until door opens after unlocking.
0 = no delay
40 = 8 seconds delay
→ Closed VRR error In certain situations e.g. after a restart or a locking problem,
the control unit checks by means of a short opening movement
if the door is locked or not. This parameter allows configuring
the further behaviour in the case the door is not locked.
→ Disabled X If the door is not locked, it stops when reaching a 10 cm open-
ing width and an error message is displayed.
→ Enabled If the door is not locked, it closes again completely and an
error message is displayed.
→ Closing force 0 Briefly increases the closing force when locking and unlocking
in order to mechanically relieve the bolt.
0 = low closing pressure
40 = high closing pressure
