Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 25/ 56
→ Contrast BDE 1 20 Contrast of the display screen for 1st BDE-D.
0 = high contrast, possible streaking
40 = low contrast, display is faintly visible
→ Contrast BDE 2 20 Contrast of the display screen for 2nd BDE-D.
→ Brightness BDE 1 20 Brightness of backlight for 1st BDE-D.
0 = pale backlight for application with dull ambient light
40 = intense backlight for applications with bright ambient light
→ Brightness BDE 2 20 Brightness of backlight for 2nd BDE-D.
→ Default operating mode Determines the operating mode in the case that no BDE-D is
connected or no BDE-M is configured.
▪ Attention: If, with doors featuring a locking device, default
operating mode Locked is not set, it should be expected
that, in case of defect BDE-D or connection interruption, a
locked door unlocks without being noticed. Therefore, the
selection of the default operating mode should be defined
together with the end customer.
→ Off Off operating mode (see warning above).
→ Locked X Locked operating mode
→ Automatic RED Automatic operating mode (see warning above)
→ Continuously open Continuously open operating mode (see warning above)
→ One-Way One-Way operating mode (see warning above)
LOCKING
→ Locking function This parameter defines in which operating modes a door
should be locked.
▪ With RED doors the only possible setting is Normally
locked
.
→ Normally locked X Locking is only possible in operating mode Locked . A locked
door can be opened with SSK.
→ One-Way locked The door can be locked in Locked and One-Way operating
modes. A locked door can be opened with AKI ( One-Way ) or
SSK ( Locked and One-Way ).
→ Always locked Locking can be performed in Locked , One-Way and Automatic
operating modes. A locked door can be opened with AKA ( Au-
tomatic ), AKI ( Automatic , One-Way ) or SSK ( Locked , One-
Way , Automatic ).
