Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 24/ 56
→ Analogue BDE-A Mechanical BDE for USA.
BDEM_1 Opening width
0V Complete opening width
24V Reduced opening width
BDEM_2 Operating mode
approx. 2.5V OFF
approx. 7.5V Continuously open
approx. 13V One-Way
approx. 19V Automatic
→ Standard Reduced BDEM_2 BDEM_1 Oper. mode Open. width
0V 0V Locked Unchanged
0V 24V Cont. open Unchanged
24V 0V Automatic Total
24V 24V Automatic Reduced
→ Analogue Reduced BDEM_2 Operating mode Opening width
approx. 2.5V Locked Unchanged
approx. 7.5V Continuously open Unchanged
approx. 13V Automatic Reduced
approx. 19V Automatic Total
→ BDE-D Settings for control unit with display.
▪ All parameters for the BDE-D are saved in the STM. Some
parameter changes are only overtaken by the BDE-D after
a restart of the controller.
→ Language Range of languages for text displays on the BDE-D.
Currently, the following languages are available: DEUTSCH,
FRANÇAIS, ENGLISH, ENGLISH US, ITALIANO, ESPAÑOL,
NEDERLANDS, DANISH, SLOVENSCINA, POLSKI, MAG-
YAR and CZECH.
▪ Older BDE-D hardware offers a limited range of languages
due to its reduced memory.
→ Keyboard Layout and function of the keys.
→ Normal X Standard layout
→ OFF-Mode Layout for the USA. The Locked key activates the operating
mode
OFF
instead of mode
Locked
. The door goes into
Man-
ual
mode and can then be locked manually.
