Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 23/ 56
Input/Output → SIO → Function
SIO
Stop
Miscellan. → Alarm display →
Collision
Enabled
→ Folding door USA Folding door for the USA with various adjustments.
CONTROL PANEL
→ BDE-M Selection of the mechanical control unit.
▪ The selection depends on the STM variant and software
version. With RED doors it is generally impossible to con-
nect a BDE-M. Locking is performed via BDE_V1/2 direct
inputs.
▪ The BDE-M can be connected either to the direct inputs of
the extended functions module FEM0 or to the configura-
ble input signals of the STM. No more than one BDE-M
may be connected at a time.
▪ BDE-D and BDE-M can be operated in parallel,
Locked
operating mode being given priority.
▪ In
Continuously open
operating mode the door goes into
Manual
mode after opening.
▪ If the BDE-M is connected to the STM, the AUX0_IN and
AUX1_IN input signals must additionally be configured.
Parameter Value
Input/Output → STG →
AUX0_IN
BDEM_2
Input/Output → STG →
AUX1_IN
BDEM_1
→ 3-positions (AUTO) BDEM_2 BDEM_1 Operating mode
0V 0V Locked
0V 24V Continuously open
24V 0V Manual
24V 24V Automatic
→ Disabled X No BDE-M is connected, signals are not evaluated.
→ Standard One-Way BDEM_2 BDEM_1 Operating mode
0V 0V Locked
0V 24V Continuously open
24V 0V Automatic
24V 24V One-way
