Record system 20 - Page 22

Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 22/ 56
→ OP door 2 Button-operated door for the hermetic closing of an operating
room.
▪
Default parameters:
Parameter Default value
Driving cycle → Ramp → Sec-
tion
20
Driving cycle → Seal 20
For more parameters, see OP
door 1
→ Folding door, Basic
escape route
This door type is a combination of Basic escape route and
Folding door door types (see above).
→ Industry 1 For protection doors on machine tools from Bühler AG, Uzwil.
▪ Dead man -control with a signal for the opening and one for
the closing of the door.
▪ Automatic or Manual operating modes can be set via
BDE-M.
▪ No collision detection 35 mm before end points.
▪ After a collision in the closing action the door reverses
direction as long as the closing command is activated. Af-
terwards, the alarm relay is activated for 2 seconds.
▪ After a collision in the opening action the door stops. Af-
terwards, the alarm relay is activated for 2 seconds.
▪ If the door is not calibrated (no running parameters) this is
displayed on the output which is normally planned for con-
necting a brake.
▪
Default parameter
s:
Parameter Default value
Driving cycle → Seal 40
Control panel → BDE-M 3 positions (AUTO)
Control panel → Default op.
mode
Automatic
Input/Output → STG →
AUX0_IN
BDE-M_2
Input/Output → STG →
AUX0_IN
OPEN DEAD MAN
Input/Output → STG →
AUX4_IN
CLOS. DEAD MAN
