Record system 20 - Page 21

Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 21/ 56
Driving cycle → Open → Creep
section
5
Time delay open → Time delay
SSK
5
Drive → Collision close 0
Control unit → BDE-D → Select
language → Français
X
Control unit → Default operat-
ing mode → Automatic
X
Output → AUX0_OUT → Fault
output
X
→ OP door 1 Button-operated door for the closing of an operating room.
▪ Parameter → Time delay open → Time delay open sets
hold-open time for reduced width, and Parameter → Time
delay open → Time delay SSK for complete width.
▪ A door opened with the Continuously open button can be
moved by hand.
▪ In order to connect all the required control elements (but-
tons) it is normal to use an STM20 DUO with the configu-
rable BDE-V inputs.
▪
Default parameters:
Parameter Default value
Driving cycle → Open → Creep
section
4
Driving cycle → Close → Creep
section
4
Time delay open → Time delay
open
10
Time delay open → Time delay
SSK
5
Input/Output → STG →
AUX0_IN
AKA BUTTON
Input/Output → STG →
AUX1_IN
CONT. OPEN
Miscellaneous → Push to actu-
ate OPEN
Normal
