Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 20/ 56
→ 3 buttons Door controlled by three keys – a key to open, a key to close
and a key to stop the door.
▪ One pulse 0V 24V with the AKI button opens the door up
to the opening width.
▪ To close the door, the button CLOSING DEAD MAN must
be maintained pressed (24V).
▪ The stop button is connected to the SIO input. Conse-
quently, the door can only be stopped in opening direction.
▪ If several keys are pressed at the same time the door
stops.
▪ A locked door can only be opened by SSK. The SSK also
has a
Dead man
function. The CLOSING button closes
and locks the door again.
▪ In
Continuously open
operating mode the door opens au-
tomatically.
▪ Default parameters:
Parameter Default value
Input/Output → STG →
AUX0_IN
AKI BUTTON
Input/Output → STG →
AUX1_IN
CLOSING DEAD MAN
Input/Output → FEM0 →
AUX2_IN
SIO
Input/Output → SIO → Function
SIO
Stop
Input/Output →
Reset
Disabled
→ Default 1 For special doors for a major customer of RTW
Parameter Default value
Driving cycle → Closing speed 40
Driving cycle → Opening speed
40
Driving cycle → Close → Creep
section
4
Driving cycle → Close → Hold-
ing force
10
Driving cycle → Open → Accel-
eration
40
Driving cycle → Open → Decel-
eration
40
